Dimensions
48 × 38 × 13.3 mm
*13.3 mm is the thickness of the watch body as measured at its thinnest location (excluding the sensor area).
**Product size, product weight, and related specifications are theoretical values only. Actual measurements between individual products may vary. All specifications are subject to the actual product.
Wrist Size
130-210 mm
M-sized strap
130-160 mm
L-sized strap
161-210 mm
Weight
Approximately 40 g (without the strap)
*Product size, product weight, and related specifications are theoretical values only. Actual measurements between individual products may vary. All specifications are subject to the actual product.
Display
1.82 inch AMOLED
480 × 408 pixels, PPI 347
Material
Aluminum alloy
Sensors
9-axis IMU sensor (Accelerometer sensor, Gyroscope sensor, Magnetometer sensor)
Optical heart rate sensor
ECG sensor
Ambient light sensor
Barometer sensor
Temperature sensor
Differential pressure sensor
Hall sensor
Button
Rotating crown
Function and ECG button
Charging Port
Wireless charging
System Requirements
Android 8.0 or later
iOS 13.0 or later
Waterproof Level
IP68
*The device meets the IP68 standard for dust and water resistance, and is not designed for swimming or other activities that involve immersion in water. It should not be work in hot showers, hot springs, or saunas (steam rooms), nor during scuba dives, deep dives, platform dives, high-pressure rinsing, or other activities that involve high water pressure, high temperatures, high levels of humidity, or fast-flowing water. Protection is not permanent, and may decrease with daily wear and tear.
Connectivity
NFC
supported
Bluetooth
2.4 GHz, Bluetooth 5.2 supporting BR and BLE
Environment
Temperature
5? to 40?
Battery Life
Data comes from Huawei labs. Actual usage may vary depending on product differences, usage habits, and environmental factors.
The battery can last for up to 6 days given typical usage.
The typical battery life is tested under the following conditions: default settings used, six blood pressure measurements and five ECG measurements per day, 30 minutes of Bluetooth calling per week, 30 minutes of music playback per week, heart rate monitoring always on, HUAWEI TruSleep™ enabled at night, stress monitoring enabled, SpO2 monitoring enabled, 90 minutes of exercise on average per week, message notifications enabled (50 messages, 6 calls, and 3 alarms per day), and the device screen turned on for a total of 30 minutes per day.
The battery can last for up to 1 day with the ABPM feature enabled.
The battery life with the ABPM feature enabled is tested under the following conditions: default settings used, ABPM enabled (with 15-min intervals), six blood pressure measurements and five ECG measurements per day, 30 minutes of Bluetooth calling per week, 30 minutes of music playback per week, heart rate monitoring always on, HUAWEI TruSleep™ enabled at night, stress monitoring enabled, SpO2 monitoring enabled, 90 minutes of exercise on average per week, message notifications enabled (50 messages, 6 calls, and 3 alarms per day), and the device screen turned on for a total of 30 minutes per day.
